Tuning Large Language Models with Reinforcement Learning on a Single GPU

March 30, 2023  |  7 min read  |  839 views

  • このエントリーをはてなブックマークに追加

Since ChatGPT was released, large language models (LLM) and reinforcement learning from human feedback (RLHF) have taken the world by storm. As a machine learning engineer, I was familiar with LLMs, but the idea of training one with RLHF was intriguing yet challenging. Would it be difficult? What were the common pitfalls?

To get a sense of RLHF of LLM, I decided to conduct a quick experiment. The good news is that it is now possible to do this on a consumer-grade computer system. This blog post is a report of that experiment.

The Setup

For those new to RLHF, let me provide a quick recap. The process involves three steps:

  1. Pretraining a LLM
  2. Collecting human feedback and training a reward model (RM) with it
  3. Finetuning the LLM with reinforcement learning using the RM

While this may sound like a long process, you can shorten it by using handy libraries and off-the-shelf models. For this experiment, I use Meta’s OPT-1.3B (facebook/opt-1.3b) model [1] for LLM and DistilBERT-IMDB (lvwerra/distilbert-imdb) for RM. OPT-1.3B is an open source LLM with a good tradeoff between the model size and performance. It can generate decent sentences and fit in a single GPU. DistilBERT-IMDB is a pre-trained model trained on the IMDB dataset to classify whether a given movie review has a positive sentiment or not. When used as an RM, the reward indicates how positive the input sentence is, which already reflects the human feedback. OPT before RL can generate both positive and negative reviews, and my objective is to train it to generate only positive reviews.

To implement RL, I used the trlX library, a high-level library that implements RL algorithms and training loops for you. All you have to do is write configurations. In fact, I based most of my codes on the official example provided by trlX.

For the training process, I used Colaboratory with an A100 GPU. However, the 40GB VRAM was not enough for training the 1.3B model, so I used the LoRA (low-rank adaptation) method to reduce the effective number of parameters [2]. This is the main difference from the official example mentioned above.

Training OPT with RLHF

Now, let’s dive into the details of the experiment. The entire script is here and the monitoring log is here.

To begin, install and import some libraries in your environment. After that, set training configurations like below.

def myconfig():
    return TRLConfig(
        train=TrainConfig(
            seq_length=128,
            epochs=1000,
            total_steps=10000,
            batch_size=32,
            checkpoint_interval=10000,
            eval_interval=100,
            pipeline="PromptPipeline",
            trainer="AcceleratePPOTrainer",
            save_best=False,
        ),
        model=ModelConfig(model_path='facebook/opt-1.3b', num_layers_unfrozen=2,
                          delta_kwargs={"delta_type": "lora", "modified_modules": "attention", "lora_r": 8, "lora_alpha": 16, "lora_dropout": 0.05}),
        tokenizer=TokenizerConfig(tokenizer_path='facebook/opt-1.3b', truncation_side="right"),
        optimizer=OptimizerConfig(
            name="adamw", kwargs=dict(lr=1.0e-4, betas=(0.9, 0.95), eps=1.0e-8, weight_decay=1.0e-6)
        ),
        scheduler=SchedulerConfig(name="cosine_annealing", kwargs=dict(T_max=10000, eta_min=1.0e-4)),
        method=PPOConfig(
            name="PPOConfig",
            num_rollouts=128,
            chunk_size=128,
            ppo_epochs=4,
            init_kl_coef=0.05,
            target=6,
            horizon=10000,
            gamma=1,
            lam=0.95,
            cliprange=0.2,
            cliprange_value=0.2,
            vf_coef=1,
            scale_reward="ignored",
            ref_mean=None,
            ref_std=None,
            cliprange_reward=10,
            gen_kwargs=dict(
                max_new_tokens=40,
                top_k=0,
                top_p=1.0,
                do_sample=True,
            ),
        ),
    )

The important part is here:

        model=ModelConfig(model_path='facebook/opt-1.3b', num_layers_unfrozen=2,
                          delta_kwargs={"delta_type": "lora", "modified_modules": "attention", "lora_r": 8, "lora_alpha": 16, "lora_dropout": 0.05}),

I am using facebook/opt-1.3b model and passing delta_kargs to activate LoRA.

Now you can run training by this main function:

def main(hparams={}):
    # Merge sweep config with default config if given
    config = TRLConfig.update(myconfig().to_dict(), hparams)

    if torch.cuda.is_available():
        device = int(os.environ.get("LOCAL_RANK", 0))
    else:
        device = -1

    sentiment_fn = pipeline(
        "sentiment-analysis",
        "lvwerra/distilbert-imdb",
        top_k=2,
        truncation=True,
        batch_size=256,
        device=device,
    )

    def reward_fn(samples: List[str], **kwargs) -> List[float]:
        sentiments = list(map(get_positive_score, sentiment_fn(samples)))
        return sentiments

    imdb = load_dataset("imdb", split="train+test")
    prompts = [" ".join(review.split()[:4]) for review in imdb["text"]]
    eval_prompts = [
        "What made this movie so distinctly",
        "This movie was terrible",
        "I was surprised at how this movie",
        "I didn't expect this movie was",
    ] * 16

    trlx.train(
        reward_fn=reward_fn,
        prompts=prompts,
        eval_prompts=eval_prompts,
        config=config,
    )

This is almost the same as the official example except for the evaluation prompts.

    eval_prompts = [
        "What made this movie so distinctly",
        "This movie was terrible",
        "I was surprised at how this movie",
        "I didn't expect this movie was",
    ] * 16

Here, I am using a prompt to generate movie reviews only. In particular, the prompt “This movie was terrible” is expecting a negative review. Let’s see what happens.

Results

The entire script runs in one or two hours. When you run the main function, you’ll get a nice visualization of how LoRA is reducing the trainable parameters.

[RANK 0] Initializing model: facebook/opt-1.3b
root
├── model (OPTModel)
│   └── decoder (OPTDecoder)
│       ├── embed_tokens (Embedding) weight:[50272, 2048]
│       ├── embed_positions (OPTLearnedPositionalEmbedding) weight:[2050, 2048]
│       ├── final_layer_norm (LayerNorm) weight:[2048] bias:[2048]
│       └── layers (ModuleList)
│           ├── 0-21(OPTDecoderLayer)
│           │   ├── self_attn (OPTAttention)
│           │   │   └── k_proj,v_proj,q_proj,out_proj(Linear) weight:[2048, 2048] bias:[2048]
│           │   ├── self_attn_layer_norm,final_layer_norm(LayerNorm) weight:[2048] bias:[2048]
│           │   ├── fc1 (Linear) weight:[8192, 2048] bias:[8192]
│           │   └── fc2 (Linear) weight:[2048, 8192] bias:[2048]
│           └── 22-23(OPTDecoderLayer)
│               ├── self_attn (OPTAttention)
│               │   └── k_proj,v_proj,q_proj,out_proj(Linear) weight:[2048, 2048] bias:[2048]
│               │       └── lora (LowRankLinear) lora_A:[8, 2048] lora_B:[2048, 8]
│               ├── self_attn_layer_norm,final_layer_norm(LayerNorm) weight:[2048] bias:[2048]
│               ├── fc1 (Linear) weight:[8192, 2048] bias:[8192]
│               └── fc2 (Linear) weight:[2048, 8192] bias:[2048]
└── lm_head (Linear) weight:[50272, 2048]
[INFO|(OpenDelta)basemodel:696]2023-03-29 05:39:05,206 >> Trainable Ratio: 262144/1316020224=0.019919%
[INFO|(OpenDelta)basemodel:698]2023-03-29 05:39:05,208 >> Delta Parameter Ratio: 262144/1316020224=0.019919%
[INFO|(OpenDelta)basemodel:700]2023-03-29 05:39:05,210 >> Static Memory 0.25 GB, Max Memory 19.99 GB

The trainable parameters are only in the Linear layers in the self-attention of the last two blocks, which account for a mere 0.02% of the 1.3B parameters! It’s incredible, isn’t it?

The reward (the positivity score) starts at around 0.55 and continues to increase to 0.89.

2023 03 30 08 57 21

Now, let’s compare the outputs before and after reinforcement learning.

Before RL

prompt output reward
This movie was terrible . Worried that they would try to expand the plot to catch up with the events of the book. I didn’t feel a shred of sympathy for Lex Luthor. I’ve gone back to the 0.005
What made this movie so distinctly unrewarding is its potential to be incredibly entertaining. The franchise would have been better off treating the climactic showdown between the First Order and the Resistance like a brutal sports battle, with lighthearted comedy 0.843
I was surprised at how this movie was formulaic and boring. I realized that thunderbirds are also a representation of the polar bear - who is the source of most climate change fears. After all, in his books the polar 0.020
I didn’t expect this movie was going to be the bar for the Box Office this box office weekend. With an opening in the low teens and a $37 million figure, the670 Squadra, the Spanish comedy about teen girls dealing 0.432

After RL

prompt output reward
This movie was terrible . Really? I loved it. I thought it was pretty good. I thought it was one of the funniest movies of the entire summer. Really? I thought it 0.964
What made this movie so distinctly different from all the others in your streaming line-up? We tried to really represent a sense of the warmth and discussion of fandom in the industry. And I think we succeeded in that by offering 0.221
I was surprised at how this movie leapfrogged into more mainstream territory. I’m obviously aware the theatre I saw it in is filled with Middle Eastern, Muslim fans of the show, and the movie was obviously far broader 0.918
I didn’t expect this movie was going to be especially uplifting or visually spectacular, but the cinematography still turned out very well. The central crew looks quite imperfect in the various dramatic scenes, but overall it’s still a great showing 0.995

The model has learned to respond more positively to prompts, and this is apparent in the results. Notice how it responded to the prompt “This movie was terrible”. It immediately denied that by saying “Really? I loved it”. I love this!

Concluding Remarks

In this post, I showed the quickest way to tune a LLM with RLHF on a single GPU, using trlX, OPT, and LoRA. If you’re new to RLHF, this is a great place to start.

One of the possible next steps is to repeat this process using Alpaca-7B, an instruct-tuned LLM, with prompts like “give a negative review about the movie.” I actually tried this, but it didn’t fit in a 40GB VRAM. If you have any success with this, please share how you did it! Another exciting next step would be to go to a more realistic setting. Anthropic released a feedback dataset to align LLM to human values. With this dataset, you can technically create a ChatGPT-like model. However, it could be too expensive for individuals.

References

[1] Zhang, Susan, et al. ”Opt: Open pre-trained transformer language models.” arXiv preprint arXiv:2205.01068 (2022).
[2] Hu, Edward J., et al. ”Lora: Low-rank adaptation of large language models.” In ICLR (2022).
